Switch 8-Port Gigabit Desktop with 8-Port PoE+ + 2x SFP Port TL-SG2210MP TP-LINK

HARDWARE FEATURES

• Standards and Protocols:
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af,
IEEE 802.3x, IEEE 802.1q, IEEE 802.1p, IEEE 802.3at, IEEE 802.3z
• Interface:
9× 10/100/1000 Mbps RJ45 Ports
1× 1000 Mbps Combo SFP/RJ45 Port
AUTO Negotiation/AUTO MDI/MDIX
• Network Media
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
• Fan Quantity: Fanless
• Power Supply: External Power Adapter (Output: 53.5 VDC/2.43 A)
• PoE Ports (RJ45) Standard: 802.3 af/at compliant
• PoE Ports: Port 1- Port 8
• PoE Power Budget: 123 W
• Max Power Consumption:
7.66 W (220V / 50Hz with no PD connected)
141.54 W (220V / 50Hz with 123 W PD connected)
• Max Heat Dissipation: 26.12 BTU/h (220V / 50Hz with no PD connected)
482.65 BTU/h (220V / 50Hz with 123 W PD connected)

PERFORMANCE
• Switching Capacity: 20 Gbps
• Packet Forwarding Rate: 14.88 Mpps
• MAC Address Table: 4 K
• Jumbo Frame: 16 KB

SOFTWARE FEATURES
• Quality of Service:
Support Port-Based/802.1p/DSCP priority
Support 4 priority queues
Rate Limit
Storm Control
• L2 Features
IGMP Snooping V1/V2/V3
Static Link Aggregation
Port Mirroring
Cable Diagnostics
Loop Prevention
• VLAN
Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
MTU/Port/Tag VLAN
• PoE:
Extend Mode**
PoE Auto Recovery
• Management: Web-based GUI
• Easy Smart Configuration Utility
• Transmission Method: Store-And-Forward

OTHERS
• Certification: FCC, CE, RoHS
• Package Contents: TL-SG1210MPE
• Power Adapter
• Installation Guide
• Rubber Feet
• System Requirements: Microsoft® Windows® for running Utility
• Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
• Storage Temperature: -40℃~70℃ (-40℉~158℉)
• Operating Humidity: 10%~90%RH non-condensing
• Storage Humidity: 5%~95%RH non-condensing

• Dimensions ( W x D x H ): 8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm)
