Relay 24VAC 10A 11Pins τύπου λυχνίας 60.13.8.024.0040 Finder
Κατόπιν Παραγγελίας
Προβολή
Τεχνικές προδιαγραφέςΤεχνικές προδιαγραφές
Contacts configuration : 3PDT
Rated coil voltage: 24V AC
Contact current max. : 10A
AC contacts rating @R(at resistive load)at resistive load 10A / 250V AC
DC contacts rating @R(at resistive load)at resistive load 10A / 30V DC
Switched voltage max. 220V DC, max. 400V AC
Operating temperature: -40...70°C
Body dimensions: 36.4x32.5x54.2mm
Coil resistance : 74Ω
Coil current : 90mA
Contact material: AgNi
Coil power consumption : 2.2VA
Leads stud terminals
Number of pins : 11
Electrical connection round socket
