Media Converter Single-Mode 10/100Mbps 20Km MC110CS TP-LINK
Προβολή
Οδηγίες Χρήσης
Τεχνικές προδιαγραφές
The MC110CS is a media converter designed to convert 100BASE-FX fiber to 100Base-TX copper media or vice versa.
Designed under IEEE 802.3u 10/100Base-TX and 100Base-FX standards, the MC110CS is designed for use with single-mode fiber cable utilizing the SC-Type connector.
The MC110CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1310nm on both transmitting and receiving data.
Other features of this module include the ability to be used as a stand alone device (no chassis required) or with TP-LINK´s 19´´ system chassis, Auto MDI/MDI-X for TX port, Auto negotiation of duplex mode on TX port and front panel status LEDs.
The MC110CS will transmit at extended fiber optic distances utilizing single-mode fiber up to 20 kilometers.
