Καλώδιο 75ohm 0.41mm class A bieffe BF6004

CONSTRUCTION PROPERTIES
material data dimension
1° - Inner conductor: copper clad steel 40% CW Ø 0,41 mm
2° - Insulation: foam antiaging Polyethylene PEE Ø 1,90 mm
3° - Tape: Aluminium/polyester/aluminium AL/PET/AL 100 %
4° - Braid: tinned copper wires CU - Sn Ø 2,60 mm
5° - Film: Polyester
6° - Sheath: Polyvinylchloride antimigrating PVC Ø 3,60 mm
coloursWHITE

ELECTRICAL SPECIFICATIONS
Screening Attenuation: >85
Braid coverage 60
DC Resistance:I n n e r C o n d uctor 320
Outer Conductor 31 Attenuation dB/100 m
Nominal Impedance 75 +/- 2 Frequency
Capacitance approx 55 +/- 2 5 MHz dB 3,8
Velocity ratio 85 50 MHz dB 10,8
Maximum voltage (spark test) 2,5 200 MHz dB 21,0

Attenuation dB/100 m
5 MHz dB 3,8
50 MHz dB 10,8
200 MHz dB 21,0
300 MHz dB 25,8
470 MHz dB 32,9
860 MHz dB 44,5
1000 MHz dB 50,0
1750 MHz dB 64,6
2150 MHz dB 72,0
2500 MHz dB 75,0
3000 MHz dB 86,4
