IC Audio Amplifiers TO-220-5 LM1875T

Manufacturer: Texas Instruments
Product Category: Audio Amplifiers

Class: Class-AB
Output Power: 25 W
Mounting Style: Through Hole
Type: Audio Power Amplifier
Package/Case: TO-220-5
Audio - Load Impedance: 8 Ohms
THD plus Noise: 0.015 %
Supply Voltage - Max: 60 V
Supply Voltage - Min: 16 V
Minimum Operating Temperature: 0 C
Maximum Operating Temperature: + 70 C
Height: 8.64 mm
Input Type: Analog
Length: 10.16 mm
Output Type: 1-Channel Mono
Supply Type: Single, Dual
Width: 4.57 mm
Supply Current - Max: 100 mA
Dual Supply Voltage: +/- 9 V, +/- 12 V, +/- 15 V, +/- 18 V, +/- 24 V, +/- 28 V
GBP - Gain Bandwidth Product: 5.5 MHz
Ib - Input Bias Current: 2 uA
Maximum Dual Supply Voltage: +/- 30 V
Minimum Dual Supply Voltage: +/- 8 V
Operating Supply Current: 70 mA
Operating Supply Voltage: 18 V, 24 V, 28 V
Output Signal Type: Single
PSRR - Power Supply Rejection Ratio: 95 dB
