IC IGBT MODULE 100A/1200V ZG100HFL120C1S
Αναμένεται Σύντομα
Προβολή
Product Description
SJ IGBT Power Module provides ultra low conduction loss as well as short circuit ruggedness. It's designed for the applications such as SMPS and UPS.
Features
High short circuit capability, self limiting to 6*I
Ultra low loss IGBT technology
Low inductance case
Fast & soft reverse recovery anti-parallel FWD
Latch-up free
Isolated copper baseplate using DCB Direct Copper Bonding technology
Typical Applications
Switching mode power supplies
DC servo and robot drives
AC motor speed control
UPS
General power switching applications
Inverters and DC Choppers
Electronic welders at fsw up to 20kHz
Low loss and fast series
ZG100HFL120C1S
Tc25° C A 170
Tc=80° C A 75
VCE V 1200
VCE 25° Ctyp. V 1.80
(Eon+Eoff) 125° Ctyp. MJ 22.00
Rth(j-c) ° C /W 0.160
SJ IGBT Power Module provides ultra low conduction loss as well as short circuit ruggedness. It's designed for the applications such as SMPS and UPS.
Features
High short circuit capability, self limiting to 6*I
Ultra low loss IGBT technology
Low inductance case
Fast & soft reverse recovery anti-parallel FWD
Latch-up free
Isolated copper baseplate using DCB Direct Copper Bonding technology
Typical Applications
Switching mode power supplies
DC servo and robot drives
AC motor speed control
UPS
General power switching applications
Inverters and DC Choppers
Electronic welders at fsw up to 20kHz
Low loss and fast series
ZG100HFL120C1S
Tc25° C A 170
Tc=80° C A 75
VCE V 1200
VCE 25° Ctyp. V 1.80
(Eon+Eoff) 125° Ctyp. MJ 22.00
Rth(j-c) ° C /W 0.160
