Dream Wall UniFi Controller switch 17xGigabit 2xSFP+ Wi-Fi 6 AP Ubiquiti

 Τεχνικές προδιαγραφές

Specifications

• Mechanical
- Dimensions: 549 x 342 x 62 mm (21.6 x 13.5 x 2.4")
- Weight: 8.6 kg (19 lb)
- Enclosure material: Polycarbonate, galvanized steel, aluminum alloy
- Mount material: Stainless steel

• Hardware
- Processor: Quad-core ARM® Cortex®-A57 at 1.7 GHz
- System memory: 4 GB DDR4
- On-board storage: 16 GB eMMC
- Integrated: 128 GB SSD
- Pre-installed: 512 GB microSD card
- Expansion slot: Micro SD memory card*
*Requires a memory card with at least 128 GB of storage.
• Management interface
- Ethernet
- Bluetooth
- WiFi
• Networking interface
- LAN:
(17) GbE RJ45 ports
(1) 10G SFP+ port

- WAN:
(1) 2.5 GbE RJ45 port
(1) 10G SFP+ port

- PoE interface:
(4) PoE (Pair A 1, 2+; 3, 6-)
(4) PoE+ (Pair A 1, 2+; 3, 6-)
(4) PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
- Power method: Universal AC input 100—240V AC, 7A Max., 50/60Hz
- Power supply: (2) Hot-Swappable AC/DC 550W PSU*
*Comes with (1) pre-installed PSU.
- Max. power consumption: 532W (Including PoE output)
- PoE budget: 420W

• Max. PoE wattage per port by PSE
- PoE: 15.4W
- PoE+: 30W
- PoE++: 60W

• Voltage range PoE mode
- PoE: 44—57V
- PoE+/PoE++: 50—57V

• Max. TX power
- 2.4 GHz: 23 dBm
- 5 GHz: 26 dBm

• MIMO
- 2.4 GHz: 2 x 2
- 5 GHz: 4 x 4

• Throughput rate
- 2.4 GHz: 300 Mbps
- 5 GHz: 2.4 Gbps

• Antenna gain
- 2.4 GHz: 5.9 dBi
- 5 GHz: 6 dBi

- ESD/EMP protection: Air: ± 8kV, contact: ± 4kV
- LCM display: (1) 4.7" touchscreen
- Button Factory reset
- Mounting: Wall mount (included)
- Operating temperature: -10 to 40° C (14 to 104° F)
- Operating humidity: 5 to 95% noncondensing

• Gateway Features
- Performance; Redundant WAN with failover and load balancing
- WiFi QoS with UniFi APs
- Application, domain, and country-based QoS
- Application and device type identification
- Additional internet failover with LTE Backup
- Internet quality and outage reporting

• Next-generation security
- Application-aware firewall rules
- Signature-based IPS/IDS threat detection
- Content, country, domain, and ad filtering
- VLAN/subnet-based traffic segmentation
- Full stateful firewall

• Advanced networking
- License-free SD-WAN
- WireGuard, L2TP and OpenVPN server
- OpenVPN client
- OpenVPN and IPsec site-to-site VPN
- One-click Teleport and Identity VPN
-Policy-based WAN and VPN routing
- DHCP relay
- Customizable DHCP server
- IGMP proxy
- IPv6 ISP support

• Software
- WiFi standards: 802.11a/b/g/n/ac/ax
- Wireless security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
- BSSID: 8 per radio
- VLAN: 802.1Q
- Advanced QoS: Per-user rate limiting
- Guest traffic isolation: Supported
- Concurrent clients: 300+

• LEDs
- Ethernet White: link/activity
- SFP+ White: link/activity
- PSU Blue: ready
- Amber: failure

• Supported Data Rates
- 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11b: 1, 2, 5.5, 11 Mbps
- 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11n (WiFi 4): 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
- 802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
- 802.11ax (WiFi 6): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)

- Certifications: CE, FCC, IC
