Dream Router UniFi Controller switch 4xGigabit 1xSFP+ Wi-Fi 6 AP Ubiquiti

 Τεχνικές προδιαγραφές

Specifications

• Mechanical
- Dimensions: Ø110 x 184.1 mm (Ø4.3 x 7.3")
- Weight: 1.2 kg (2.5 lb)
- Enclosure material: Polycarbonate

• Hardware
-Processor: Dual-core Arm® Cortex® A53 at 1.35 GHz
- System memory: 2 GB
- Expansion slot: Micro SD memory card*
*Requires a memory card with at least 128 GB of storage.

• Management interface
- Ethernet
- Bluetooth

• Networking interface
- LAN:
(4) GbE RJ45 ports

- WAN:
(1) GbE RJ45 port

- PoE interface: (2) PoE (Pair B 4, 5+; 7, 8-)
- Power method: Universal AC input, 100—240V AC, 1.1A Max., 50/60 Hz
- Power supply: AC/DC, internal, 50W
- Supported voltage range: 100—240V DC
- Max. power consumption: 19.37W (Excluding PoE output)
- PoE budget: 40W
- Max. PoE wattage per port by PSE: 15.4W
- Voltage range PoE mode: 44—57V DC

• Max. TX power
- 2.4 GHz: 26 dBm
- 5 GHz: 26 dBm

• MIMO
- 2.4 GHz: 4 x 4
- 5 GHz: 4 x 4

• Throughput rate
- 2.4 GHz: 600 Mbps
- 5 GHz: 2.4 Gbps

• Antenna gain
- 2.4 GHz: 3.4 dBi
- 5 GHz: 4.3 dBi

- Antenna: (1) Internal, dual-band, quad-polarity antenna
- LCM display: (1) 0.96" screen
-Button: Factory reset
- LEDs: White/blue
- Operating temperature: -10 to 45° C (14 to 113° F)
- Operating humidity: 5 to 95% noncondensing

• Gateway Features
• Performance:
- Redundant WAN with failover and load balancing
- WiFi QoS with UniFi APs
- Application, domain, and country-based QoS
- Application and device type identification
- Additional internet failover with LTE Backup
- Internet quality and outage reporting

• Next-generation security
- Application-aware firewall rules
- Signature-based IPS/IDS threat detection
- Content, country, domain, and ad filtering
- VLAN/subnet-based traffic segmentation
- Full stateful firewall

• Advanced networking
- License-free: SD-WAN
- WireGuard, L2TP and OpenVPN server
- OpenVPN client
- OpenVPN and IPsec site-to-site VPN
- One-click Teleport and Identity VPN
- Policy-based WAN and VPN routing
- DHCP relay
- Customizable DHCP server
- IGMP proxy
- IPv6 ISP support

• Software
- WiFi standards: 802.11a/b/g/n/ac/ax
- Wireless security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
- BSSID: 8 per radio
- VLAN: 802.1Q
- Advanced QoS: Per-user rate limiting
- Guest traffic isolation: Supported
- Concurrent clients: 300+

• Supported Data Rates
- 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11b: 1, 2, 5.5, 11 Mbps
- 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11n (WiFi 4): 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
- 802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
- 802.11ax (WiFi 6): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)

- Certifications: CE, FCC, IC
