Ανεμιστήρας 48VDC 172x172x51 mm 6314/2TDHHP ΡΟΥΛΕΜΑΝ EBM-PAPST
-24%
Αναμένεται Σύντομα
Προβολή
General description 3-phase fan drive with very smooth operation and high efficiency Housing with earthing lug for bolt M4 x 8 (Torx) Free air power consumption, these values may be considerably higher at the operating point.
Impeller material Fibreglass-reinforced plastic (PA)
Housing material Die-cast aluminium
Direction of air flow Air exhaust over bars
Direction of rotation Counterclockwise, looking at rotor
Bearing Ball bearings
Lifetime L10 at 40 °C 62500 h
Lifetime L10 at maximum temperature 25000 h
Connection line via single strands AWG 18, 20 or AWG 22, TR 64, speed signal and control input AWG 22
Motor protection Protected against reverse polarity and locking.
Dimensions 172 Ø x 51 mm
Mass 910 gr
**με μεταλλικό πλαίσιο και πλαστικό φτερό**
Impeller material Fibreglass-reinforced plastic (PA)
Housing material Die-cast aluminium
Direction of air flow Air exhaust over bars
Direction of rotation Counterclockwise, looking at rotor
Bearing Ball bearings
Lifetime L10 at 40 °C 62500 h
Lifetime L10 at maximum temperature 25000 h
Connection line via single strands AWG 18, 20 or AWG 22, TR 64, speed signal and control input AWG 22
Motor protection Protected against reverse polarity and locking.
Dimensions 172 Ø x 51 mm
Mass 910 gr
**με μεταλλικό πλαίσιο και πλαστικό φτερό**
