Ανεμιστήρας 24V DC 80x80x25mm SLEEVE EF80252S1 SUNON
Προβολή
Specification
Bearing : Sleeve
Fan type DC
Bearing type slide bearing
Fans efficiency 69.7m3/h
Noise level 33dBA
Supply voltage 24V DC
Power consumption 1.8W
Operating voltage 10...27.6V
Rotational rate/speed 3200 (±10%)rpm
Rated current 0.073A
Current and power consumption tolerance ±15%
Min. insulation resistance 500MΩ
Fan material thermoplastic
Enclosure material thermoplastic
Insulation class E
Operating temperature -10...70°C
Static pressure 4.57mm H2O
Leads 2 leads
Flammability rating UL94V-0
Fan motor brushless DC motor
Cable length 300mm
Wire size 28AWG
Additional functions Autorestart
Fan dimensions 80x80x25mm
Weight 75 gr
