Ανεμιστήρας 12V DC 70x70x20mm EE70201S3 Sunon
Προβολή
Specification
Fan type DC
Bearing type Sleeve
Fans efficiency 23.50m3/h
Noise level 26dBA
Supply voltage 12V DC
Power consumption 1.08W
Operating voltage 4.5...13.8V
Rotational rate/speed 2600 (±15%)rpm
Rated current 0.09A
Current and power consumption tolerance ±15%
Min. insulation resistance 500MΩ
Fan material thermoplastic
Enclosure material thermoplastic
Insulation class E
Operating temperature -10...70°C
Static pressure 1.02mm H2O
Leads 2 leads
Flammability rating UL94V-0
Fan motor brushless DC motor
Cable length 300mm
Wire size 28AWG
Additional functions Autorestart
Fan dimensions 70x70x20mm
Weight 60gr
