Ανεμιστήρας 12V DC 120x120x38mm EEC0381B1 2 ρουλεμάν Sunon
-19%
Προβολή
Specification
Fan type DC
Bearing type 2 x ball bearing
Fans efficiency 234.4m3/h
Noise level 48dBA
Supply voltage 12V DC
Power consumption 9.6W
Operating voltage 6...13.8V
Rotational rate/speed 3100 (±10%)rpm
Rated current 0.8A
Current and power consumption tolerance ±15%
Min. insulation resistance 10MΩ
Fan material thermoplastic
Enclosure material thermoplastic
Insulation class A
Operating temperature -10...70°C
Static pressure 9.14mm H2O
Leads 2 leads
Flammability rating UL94V-0
Fan motor brushless DC motor
Cable length 310mm
Wire size 28AWG
Additional functions Autorestart
Fan dimensions 120x120x38mm
Weight 214 gr
Ref Code: 039279
