Access Point 2.4+5+6 GHz 3.2+5.3+6 dBi 570+4800+4800 Mbps 1x2.5GbE Wi-Fi 6 U6-Enterprise Ubiquiti

 Τεχνικές προδιαγραφές

Specifications

• Mechanical
- Dimensions: Ø220 x 48 mm (Ø8.7 x 1.9")
- Weight
- Without mount: 960 g (2.1 lb)
- With mount: 1090 g (2.4 lb)
- Enclosure material: Polycarbonate, aluminum
- Mount material: Stainless steel (SUS304)

• Hardware
- Networking interface: (1) 2.5 GbE RJ45 port
- Management interface: Ethernet
- Bluetooth
- Power method: PoE+
- Power supply: UniFi PoE switch
- 48V, 0.5A PoE adapter (Optional)
- Supported voltage range: 44—57V DC
- Max. power consumption: 22W
• Max. TX power
- 2.4 GHz: 22 dBm
- 5 GHz: 26 dBm
- 6 GHz: 26 dBm

• MIMO
- 2.4 GHz: 2 x 2 (UL MU-MIMO)
- 5 GHz: 4 x 4 (DL/UL MU-MIMO)
- 6 GHz: 4 x 4 (DL/UL MU-MIMO)

• Throughput rate
- 2.4 GHz: 573.5 Mbps
- 5 GHz: 4.8 Gbps
- 6 GHz: 4.8 Gbps

• Antenna gain
- 2.4 GHz: 3.2 dBi
- 5 GHz: 5.3 dBi
- 6 GHz: 6 dBi

- LEDs: White/blue
- Button: Reboot and factory-reset
- Mounting: Wall, ceiling (Included)
- Operating temperature: -30 to 60° C (-22 to 140° F)
- Operating humidity: 5 to 95% noncondensing

• Software
- WiFi standards: 802.11a/b/g/n/ac/ax (WiFi 6/6E)
- Wireless security: WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
- BSSID: 8 per radio
- VLAN: 802.1Q
- Advanced QoS: Per-user rate limiting
- Guest traffic isolation: Supported
- Concurrent clients: 600+
-Zero-wait DFS: Yes*
*Supported with upcoming firmware versions.

• Supported Data Rates (Mbps)
- 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11b: 1, 2, 5.5, 11 Mbps
- 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11n (WiFi 4): 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
- 802.11ac (WiFi 5): 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
- 802.11ax (WiFi 6/6E): 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)

• Application Requirements
- UniFi Network: Version 7.2.91 and later

- Certifications: CE, FCC, IC
